Surenoo Graphic LCD Module

Surenoo Display Selection Guide for Graphic LCD Module

Model No. SPU	Format	Outline Size (MM)	View Area (MM)	Active Area (MM)	Voltage	Interface	Mark	Datasheet	Controller	Buy Now (Image)
XXX32 Display Series
2.0" SLG12232A 10289251	122X32 Dots	84.00*44.00	60.50*18.00	48.76*14.68	5.0V	1X16P/2.54 1X8P/2.54 Parallel Serial SPI			ST7920
2.0" SLG12232B 10324729	122X32 Dots	84.00*44.00	60.50*18.00	48.76*14.68	5.0V	1X18P/2.54 Parallel			SED1520 SBN1661 AIP31520
2.0" SLG12232C 10324115	122X32 Dots	76.60*28.00	60.50*18.00	C1: 48.76*14.68 C2: 54.86*14.36	5.0V	1X7P/2.54 Serial SPI	Thickness C1: 8.60MM C2: 13.00MM		ST7920
2.0" SLG12232D 10668807	122X32 Dots	80.00*36.00	60.50*18.00	53.64x15.64	5.0V	1X20P/2.54 Parallel			SED1520 SBN1661 AIP31520
2.0" SLG12832A 10684426	128X32 Dots	56.80*33.00	52.00*16.00	49.00*14.00	3.3V	1X20P/2.54 Parallel Serial SPI	COG		ST7567
2.4" SLG14432A 10710193	144X32 Dots	80.00*36.00	64.50*16.00	60.45x13.41	5.0V	1X18P/2.54 Parallel Serial SPI			ST7920
3.12" SLG16032A 10733541	160X32 Dots	116.00*35.00	82.90*18.50	76.76*15.32	5.0V	2X8P/2.54 Parallel Serial SPI			ST7920
3.5" SLG16032B 10750296	160X32 Dots	122.00*44.00	99.00*24.00	89.55*18.19	5.0V	1X20P/2.54 Parallel Serial SPI			ST7920
19264 Display Series
3.2" SLG19264A 10796174	192X64 Dots	100.00*60.00	84.00*31.00	78.68*26.20	5.0V	1X20P/2.54 Parallel			KS0108
4.0" SLG19264B 10805211	192X64 Dots	130.00*65.00 127.00*62.00	104.00*39.00	95.58*31.83	5.0V	1X20P/2.54 Parallel			KS0108
4.0" SLG19264C 10809422	192X64 Dots	130.00*65.00	104.00*39.00	97.49*32.46	5.0V	1X20P/2.54 Parallel Serial SPI			ST7920
4.0" SLG19264D 10809203	192X64 Dots	130.00*65.00	104.00*39.00	97.50*32.47	5.0V	1X5P/2.54 UART RS232
4.0" SLG19264E 10889670	192X64 Dots	130.00*65.00	104.00*39.00	97.49*32.46	5.0V	1X20P/2.54 Parallel Serial SPI	COG		ST7525
1.9" SLG19264F 10909575	192X64 Dots	66.00*26.00	51.00*17.20	47.98*15.98	3.3V	1X9P/2.54 Serial SPI	COG		UC1609C
2.0" SLG19264G 10897634	192X64 Dots	61.50*23.27 56.20*23.24	47.50*17.49	45.68*15.21	3.3V	1X12P/2.0 Serial SPI	COG		UC1604C
24064 Display Series
5.2" SLG24064A 11086905	240X64 Dots	180.00*65.00	132.00*39.00	127.16*33.88	5.0V	2X11P/2.54 Parallel			UCi6963
5.0" SLG24064B 11151220	240X64 Dots	164.00*65.00	135.00*35.00	125.98*28.46	3.3V	2X10/2.54 Parallel	COG		ST75256
5.2" SLG24064C 11104219	240X64 Dots	180.00*65.00	132.60*39.00	127.16*33.88	5.0V	2X10+2P/2.54 Parallel			RA6963
240128 Display Series
4.7" SLG240128A 11871838	240X128 Dots	144.00*104.00	114.00*64.00	107.96*57.56	5.0V	1X21P/2.54 2X10/2.54 Parallel			RA6963
4.7" SLG240128B 11884883	240X128 Dots	144.00*104.00	114.00*64.00	107.96*57.56	5.0V	1X21P/2.54 1X22/2.54 Parallel			UCi6963
4.7" SLG240128C 11903220	240X128 Dots	144.00*104.00	114.00*61.00	105.56*56.28	5.0V	1X20P/2.54 Parallel			RA6963
3.8" SLG240128D 11931274	240X128 Dots	100.00*85.00	92.00*52.00	83.98*44.78	5.0V		COG RTP Optional		UC1608X
4.7" SLG240128E 11913935	240X128 Dots	144.00*104.00	114.00*64.00	107.96*57.56	5.0V	1X22P/2.54 2X11/2.54 Parallel	RTP		RA8806
Others Dots (25664 / 32064 / 128128 / 160128 / 160160 / 240160 / 384160)
4.2" SLG25664A 11977067	256X64 Dots	137.00*39.60	108.60*29.60	102.37*25.57	5.0V	1X20P/2.54 Parallel			KS0108
5.5" SLG32064A 11068083	320X64 Dots	190.00*54.00	147.00*29.50	137.55*26.19	5.0V	1X24P/2.54 Parallel			KS0108
2.5" SLG128128A 11751425	128X128 Dots	69.00*74.00	49.00*49.00	44.77*44.77	5.0V	1X20P/2.54 Parallel			RA6963
1.05" SLG128128B 11780624	128X128 Dots	32.67*36.39	28.67*28.67	26.67*26.67	3.3V	1X14P/0.7 FPC			IST7920
4.7" SLG160128A 11432584	160X128 Dots	129.00*102.00	101.00*82.00	92.76*74.20	5.0V	2X11P/2.54 Parallel			UCi6963
3.0" SLG160160A 11522449	160X160 Dots	83.80*76.50	60.00*60.00	54.38*54.38	3.3V	1X18P/1.0 FFC			UC1698U
3.12" SLG240160A 11434738	240X160 Dots	97.40*58.40	75.00*46.51	37.19*42.39	5.0V	2X10P/2.54 Parallel			RA8806
4.1" SLG384160A 12011857	384X160 Dots	107.50*66.60	101.80*45.80	95.98*39.98	3.3V	1X20P/2.54 Parallel			ST7586S
